| Technical data table | |||||
| TYPE | Displacement | Max. Pressure | CODE | ||
| cm3/rev | P1 bar | P3 bar | Left rotation | Right rotation | |
| X1F-1/0.9 | 1 | 240 | 280 | X1F1671TIIA | X1F1672TIIA |
| X1F-1/1.2 | 1 | 250 | 290 | X1F1771TIIA | X1F1772TIIA |
| X1F-1/1.7 | 2 | 250 | 290 | X1F1871TIIA | X1F1872TIIA |
| X1F-1/2.2 | 2 | 250 | 290 | X1F2071TIIA | X1F2072TIIA |
| X1F-1/2.6 | 3 | 250 | 300 | X1F2171TIIA | X1F2172TIIA |
| X1F-1/3.2 | 3 | 250 | 300 | X1F2371TIIA | X1F2372TIIA |
| X1F-1/3.8 | 4 | 250 | 300 | X1F2571TIIA | X1F2572TIIA |
| X1F-1/4.3 | 4 | 250 | 300 | X1F2771TIIA | X1F2772TIIA |
| X1F-1/4.9 | 5 | 250 | 300 | X1F2971TIIA | X1F2972TIIA |
| X1F-1/5.9 | 6 | 250 | 300 | X1F3171TIIA | X1F3172TIIA |
| X1F-1/6.5 | 7 | 250 | 300 | X1F3271TIIA | X1F3272TIIA |
| X1F-1/7.8 | 8 | 220 | 260 | X1F3471TIIA | X1F3472TIIA |
| X1F-1/9.8 | 10 | 190 | 230 | X1F3671TIIA | X1F3672TIIA |
P1) Max. working pressure – P3) Max. peak pressure
